Ripristino totale
Model: Assembleon Topaz X2
Category: Pick and Place/Feeders
Model Year: 2004
Condition: refurbished
Location: Italy – Padua
_______________________________
| Optimal placement rate: | 20,000 cph |
| Nominai placement rate: | 15,400 cph |
| Applicable components: | 0402 – SOP, SOJ, PLCC 32mm ( 1.26″) |
| 6mm – QFP 32mm ( 1.26″) with pin pitch down to 0.5mm (20 mii) | |
| Dark background BGA, μBGA, CSP with regular pitches; | |
| 6mm – 32mm: Min. ball pitch down to 0.75mm (31 mii}, Min. | |
| ball diameter down to 0.3mm (I 2mil) | |
| 6mm – QFP 32mm (1.26″) with pin pitch down to 0.4mm (16 mii) | |
| Dark background BGA, μBGA,CSP with regular pitches; | |
| 6mm – 32mm: Min. ball pitch down to 0.75mm (31 mii}, Min. | |
| ball diameter down to 0.3mm (I 2mil) | |
| Mounting accuracy (XY) 3σ: | ± 50μ for chips and SOIC |
| ± 40μ for QFPs ( 6mm – 32mm 1.26″) with pin pitch down to 0.5mm (20 mii) | |
| ± 35μ for QFPs (6mm – 32mm 1.26″) with pin pitch down to 0.4mm ( 16 mii) | |
| Mounting accuracy
(φ): |
For Chips and SOIC this is Lead dependent |
| ± 0.6° for QFPs (6mm – 32mm 1.26″) with pin pitch down to 0.5mm (20 mii) | |
| ± 0.09° for QFPs (6mm – 32mm 1.26″) with pin pitch down to 0.4mm ( 16 mii) | |
| Mounting angle: | O up to 360 (programmable in steps of O.O I ) |
| Mounting repeatability: | X, Y 30μ for QFPs (6mm – 32mm 1.26″) pitch 0.4 Phi (0.09°) |
| Number of heads: | One single beam with 4 Flying Nozzle change heads and 4 standard heads |
| Alignment system: | One line array camera with fore and side illumination system for |
| Vision on the Fly using the VICS 2500 processing system | |
| Area CCD camera for QFP 32mm ( 1.26″) with pin pitch | |
| down to 0.4mm ( 16 mii) | |
| Moving CCD camera for Fiducia! alignment |
Optional:
- Doppia multicamera bancata anteriore e posteriore
- Nozzle station
- Trolley FES
- 8 Standard Heads
Available 1 machine
